Artikelnummer: ASC10.51
ASC10.51 | S55845-Z103
Digital-Ausgänge Schaltspannung: AC 250 V
Digital-Ausgänge Schaltstrom: 6(3) A
Artikelnummer: SAL81.00T40
SAL81.00T40 | S55162-A107
Drehmoment: 40 Nm
Drehwinkel: 90°
Leistungsaufnahme: 6 VA
Stellzeit: 120 s
Stellsignal: 3-Punkt
Schutzart: IP54
Umgebungstemperatur Betrieb: -15…55 °C
Mediumstemperatur: -10…120 °C
Umgebungsfeuchte Betrieb: 95 % r.F.
Abmessungen (B x H x T): 160 x 124 x 153 mm
Montagelage: Stehend bis liegend
Betriebsspannung: AC/DC 24 V
Stellungsrückmeldung: DC 0...10 V (SA..6..)
Hilfsschalter: 0
Artikelnummer: SAV61.00
SAV61.00 | S55150-A110
Stellkraft: 1600 N
Hub: 40 mm
Leistungsaufnahme: 9.5 VA
Notstellfunktion: Nein
Stellsignal: DC 0…10 V, DC 4…20 mA, 0…1000 Ohm
Umgebungstemperatur Betrieb: -5…55 °C
Mediumstemperatur: -25…130 °C
Abmessungen (B x H x T): 150 x 265 x 124 mm
Montagelage: Stehend bis liegend, bis 150 °C bei horizontaler Einbaulage
Stellungsrückmeldung: DC 0...10 V
Hilfsschalter: Optional
